Frequencies

Global

2G: B2/B3/B5/B8

3G:B1/B2/B4/B5/B8

4G-FDD:B1/B2/B3/B4/B5/B7/B8/B12/B17/B20/B26/B28/B66

4G-TDD:B38/B39/B40/41

Wi-Fi

IEEE 802.11 a/b/g/n/ac

Bluetooth

BLE 5.0

NFC

Support

Navigation

GPS, GLONASS, AGP

GPS, BDS, Galileo

OS

Operating System

Android 10

DMR

Frequency Range

Global

UHF：400-480MHz

VHF：136-174MHz

Channel Capacity

2048

Channel Spacing

25KHz/12.5KHz

Power Output

UHF: High Power 4W

Low Power 1W

VHF: High Power 4W/

Low Power 2W

Receiver Sensitivity

≤-123dBm

DMR Encryption

ARC4 / AES128 / AES25

License Agreement

Tier Ⅱ

Hardware

RAM+ROM

2GB+16GB

Expand Memory

up to 32GB

Card Slot

Dual SIM Card+ TF Card

Interface

M6

OTG

Support, via the M6 interface

Screen

2.4 Inches, 480 x 640

Camera

Front camera 5.0MP; Rear camera 13.0MP,120°ultra-wide angle

Speaker

Ø36mm waterproof speaker, 8Ω 3W

Microphone

Master-microphone+Slave-microphone+Noise-cancelling microphone

Battery

Removable, 3100mAh(Standard), 4000mAh(Optional), 7.6V

Dimension

Thin Battery: 162.3 x 61x 34.5mm(Without Belt Clip and Antenna)

Thick Battery: 162.3 x 61 x 38mm(Without Belt Clip and Antenna）

Working Temperature

-20℃ ~ 60℃

Storage Temperature

-40℃ ~ 85℃

Certification

Ingress Protection

IP68

Drop

1.5 Meter

Certification

CE/FCC/MIL-STD-810H/GMS
