EU version

  GSM: B2/B3/B5/B8
  WCDMA: B1/B2/B5/B8
  TDD-LTE: B38/B39/B40/B41
  FDD-LTE: B1/B3/B5/B7/B8/B20/B28a/B28b

  US version

  GSM: B2/B3/B5/B8
  WCDMA: B1/B2/B5/B8

  FDD-LTE: B1/B2/B4/B5/B7/B12/B13/B17/B28a/B28b

  Wi-Fi

  IEEE 802.11 a/b/g/n

  Bluetooth

  4.0 & BLE

  NFC

  Support

  Navigation

  GPS, AGPS

  OS

  OS

  Android 7.1

  DMR Technical Specifications

  Frequency

  16

  25/12.5KHz

  UHF:High Power 2W /Low Power 0.5W     VHF:2W

  Tier Ⅱ

  <-120dbm

  3.2V-4.2V

  Hardware

  CPU

  MTK6739WA

  RAM+ROM

  1GB+ 8GB

  Expand Memory

  Optional, up to 32G

  Card Slot

  Dual Micro SIM card + TF card

  USB

  Micro USB 2.0

  Interface

  M6

  Screen Size

  2.4 inches, G + F single touch

  Camera

  Front Camera 2.0MP，Rear Camera 13.0MP

  Speaker

  Ø36mm，8Ω 2W

  Microphone

  Main Mic + Aux Mic

  Flashlight

  Battery

  6000mAh

  Working Times

  Public Net：18 Hours      DMR：15 Hours

  Standby Times

  Public Net：22 Hours      DMR：45 Hours

  Dimension (H*W*D)

  140 x 64 x 35mm(Without Antenna and Belt clip)

  Weight

  ≈300g

  Working Temperature

  -10°C ~ 55°C

  Storage Temperature

  -10°C ~ 60°C

  Certifications

  Ingress Protection

  IP54

  Drop

  1.2 Meter

  Certificate

  CE/FCC/ROHS/CMIIT ID:2021CP8021
