| Feature | Technical Description |
| 1、HW SPEC | |
| 1.1 Main CPU & SW | |
| CPU | MTK6739 |
| Android | Android8.1 |
| OS Language | Korean, Japanese , English , Chinese... |
| 1.2 Memory | |
| RAM+ROM | 2GB +16GB |
| SD Card | 64GB |
| 1.3 LCD | |
| LCD | TFT 5.5" |
| LCD resolution | 1280 X 720 dpi WVGA |
| LCD Colors | 16M color IPS TFT |
| 1.4 Touch | |
| Touch type & size | 5.5" / Capacitive |
| Glass | Coning generation 3 |
| Multi-touch | 5 point touch screen |
| 1.5 Sensor | |
| Sensor | G-Sensor/Gyroscope/Compass |
| 1.6 Frequency/Bands | |
| Network ( GSM . WCDMA , FDD , TDD) | EU Version: GSM:850MHz / 900MHz / 1800MHz / 1900MHz WCDMA:B1 / B2 / B5 / B8 TD-SCDMA:B34 / B39 CDMA2000:BC0 LTE-TDD:B38 / B39 / B40 / B41 LTE-FDD:B1/ B3/ B7 / B8 / B20 / B28 ( A&B ) US Version: GSM:850MHz / 1900MHz WCDMA:B1 / B2 / B4 / B5（ B19 ) LTE-FDD:B1 / B2 / B4 / B5 ( B19 ) / B7 / B12 ( B17 ) / B13 / B28 DMR:UHF 400-470MHz |
| 1.7 Camera | |
| Front& Rear Camera | Front:200M |
| 1.8 Wi-Fi | |
| IEEE802.11a | Yes (5G) |
| IEEE802.11b | Yes(2.4G) |
| IEEE802.11g | Yes(2.4G) |
| IEEE802.11n | Yes(2.4G&5G) |
| WIFI anternna Type | Wi-Fi & BT Coexistence Internal FPC antenna |
| 1.9 Bluetooth | |
| Version | BT v4.0 with BLE BT2.1 + EDR ( Enhanced Data Rate ) |
| Power Level | (Max) Class 2 |
| Operation distance | (Max) 10 meter |
| 2.0 GPS & A-GPS | |
| GLONASS Support | Yes |
| GPS Support | Yes |
| AGPS Support | Yes |
| 2.1 Speaker & MIC | |
| Output | Φ50mm,4Ω,5W |
| SPL | 106dB |
| Receiver | 1506 |
| MIC Type | Dual MIC, DMR POC Use microphone independently |
| MIC Sensitivity | -42dB±3 |
| SIM card | One Push NANO SIM Card |
| Vibrator | Yes |
| 2.2 Connector | |
| Connector Interface | DB9 Connector |
| 2.3 Earjack Interface Type | No |
| 2.4 Indicator LED | 3-colors ( Red 、 Green 、 Blue ) |
| 3、MD | |
| 3.1 Size | |
| Height ( H * W * D ) | 190 x 93 x 66mm |
| Weight | 486g |
| IP code | IP54 |
| Drop Test | Standard |
| 3.2 Key buttons | |
| keys button | PTT,SOS, Channel , Power, Volume... |
| 4、 Battery | |
| Battery Type | No |
| 5、 Charge, Data Interfaces | DP9 |
| 5.1 Peripheral Inerface | |
| External Hand mic interface | 4pin GX16 Hand mic |
| POWER SUPPLY interface | 12V input voltage |
| 5.3 DMR | |
| Channel capacity | 16 |
| Channel spacing | 12.5 / 25 kHz ( analogue ) 12.5 kHz ( digital ) |
| Transmitting Power | 0.5W/2W |
| Operation distance | 2km （Max） |
| Frequency Stability | ± 0.5ppm |
| Sensitivity | 0.22 mV ( Typical ) |
| 6、 Environmental Conditions | |
| Operating Temperature | -20℃ ~ 80℃ |
| Storage Temperature | -30℃ ~ 90℃ |
| Humidity | 20 ~ 90% |
| ESD | Contact: ± 6KV Air: ±8KV |
| RoHS 6 Compliant | Yes |
| 7、 Certification and safety spec | |
| Europe | CE |
| American | FCC |
