| Feature | Technical Description |
| 1、HW SPEC | |
| 1.1 Main CPU & SW | |
| CPU | MTK8765 ,GPU 1.5Ghz |
| Android | Android 8.1 GO |
| Language | Multi Language |
| 1.2 Memory | |
| RAM+ROM | 512MB+4GB(1GB +8GB optional ) |
| SD Card | 32GB |
| 1.3 LCD | |
| LCD | 1.77 TFT |
| LCD resolution | 128x160 RGB |
| LCD Colors | 16M Color IPS TFT |
| 1.4 Touch | |
| Touch type & size | None |
| Glass | China made |
| Multi-touch | None |
| 1.5 Sensor | |
| Sensor | G-Sersor/Acceleration Sensor |
| 1.6 Frequency/Bands | |
| Network( GSM, WCDMA, FDD, TDD） | EU band: |
| GSM: B2/B3/B5/B8 | |
| WCDMA: B1/B2/B5/B8 | |
| TD-SCDMA: B39/B34 | |
| FDD-LTE: B1 / B3 /B5/ B7 / B8 / B20 / B28 (a&b) | |
| TDD-LTE: B38 / B39 / B40 / B41 | |
| US band: | |
| GSM: B2/B3/B5/B8 | |
| WCDMA: B2/B4/B5 | |
| FDD-LTE: B2 / B4 / B5/ B7 / B12 / B17 / B28 ( a&b ) | |
| 1.7 Camera | |
| Front& Rear Camera | None |
| 1.8 Wi-Fi | |
| IEEE802.11a | Yes (5G) |
| IEEE802.11b | Yes(2.4G) |
| IEEE802.11g | Yes(2.4G) |
| IEEE802.11n | Yes(2.4G&5G) |
| WIFI anternna Type | Wi-Fi & BT Coexistence Internal antenna |
| 1.9 Bluetooth | |
| Version | BT V4.0 with BLE / BT2.1 + EDR ( Enhanced Data Rate ) |
| Power Level | (Max) Class 2 |
| Operation distance | (Max) 10 meter |
| 2.0 GPS & A-GPS | |
| GLONASS Support | None |
| GPS Support | Yes |
| AGPS Support | Yes |
| BDS | Yes |
| 2.1 Speaker & MIC | |
| Output | 3W speaker |
| SPL | 106db under AI noisy reduction |
| Receiver | 1506 |
| MIC Type | Single Pole Mic |
| MIC Sensitivity | -42dB±3 |
| SIM card | TWO Nano-SIM card |
| Vibrator | None |
| 2.2 USB | |
| USB type | TYPE C |
| USB | Micro USB2.0 |
| Cable length | 1.0m |
| 2.3 Earjack Interface Type | 3.5mm PTT |
| 2.4 Indicator LED | 3-colors(Red, Green, Blue） |
| 3、MD | |
| 3.1 Size | |
| Height ( H * W * D ) | 117 x 60 x 29.2mm |
| Weight | 261g |
| IP code | IP68 |
| Drop Test | 1.8m |
| 3.2 Key buttons | |
| keys button | PTT Key / Volume UP / Down Key / Function Key / SOS Key / Power Key/Channel knob |
| 4、 Battery | |
| Battery type | Li-Po |
| Battery capacity | 7000 mAh (Optional 5000mah) with MSDS, UN38.3.IEC62133 |
| Removable battery | Yes |
| 5.1 Charging | |
| Micro USB ( For Handset ) | Yes |
| Battery charging terminal（For Cradle) | Cradle charging |
| 5.2 Cradle Spec | |
| Input voltage | DC 5V/2.0A |
| Output voltage | DC 5V/2.0A |
| Interface Type | TYPE-C Connector (Replace old version Micro-USB) |
| 5.3 Phone Adaptor Spec | |
| Input voltage | AC 100-240V, 50 / 60Hz, 0.3A |
| Output voltage | DC 5V / 2.0A |
| Interface Type | Standard USB |
| 6、 Environmental Conditions | |
| Operating Temperature | -20℃ ~ 60℃ |
| Storage Temperature | -30℃ ~ 70℃ |
| Humidity | 20% ~ 90% |
| ESD | Contact: ±8KV |
| Air: ±12KV | |
| ROHS 6 Compliant | Yes |
| 7、 Certification and safety spec | |
| Europe | CE |
| American | FCC |
